Pressure Transmittor ：TQG14F
Silicon Piezoresistive | High Sensitivity | Stability & Reliability
The TQG14F pressure transmitter utilizes the diffused silicon piezoresistive effect to convert pressure signals into a standard 4–20 mA DC current output. With stable performance and high reliability, it is widely used in various industrial pressure monitoring applications.
TQG14F

Key Features

● Long-term stability

● Accuracy±0.5%Span

● Operating voltage 15~30VDC

● Operating temperature -25℃~+70℃

● Measuring range 0~1000kPa

● Overload capacity 2000kPa

● Output signal 4~20mA

● Insulation resistance 100MΩ

● Dielectric insulation 500Vrms/50Hz/min

● R1/2 terminal


Applications

● Pressure monitoring in railway braking and traction systems

● Other industrial measurement scenarios


DOWNLOAD
TECHNICAL DOCUMENTATION
